MIL-PRF-32517
4.4.1 Inspection of product for delivery. Inspection of product for delivery shall consist
of Group A inspections. Except as specified in 4.4.3.2, delivery of products that have passed
Group A inspection shall not be delayed pending the results of Group B inspection.
4.4.1.1 Inspection lot. An inspection lot, as far as practicable, shall consist of matched
impedance splices manufactured under essentially the same conditions and offered for inspection
at one time.
4.4.2 Group A inspection. Group A inspection shall consist of the examination and test
specified in table VIII and shall be made on the same set of sample units, in the order shown.
4.4.2.1 Sampling plan. Statistical sampling shall be in accordance with table IX. A
randomly selected group(s) of samples is required. For acceptance of the lot there shall be zero
occurrences of defects.
4.4.2.2 Rejected lots. If an inspection lot is rejected, the supplier shall withdraw the lot
and may rework it to correct the defects or screen out the defective units. Such lots shall be kept
separate from new lots and shall be re-inspected. Such lots shall be re-inspected using tightened
inspection.
TABLE VIII. Group A inspections.
Examination or test
Requirement
Test method
Sampling Plan
paragraph
paragraph
Visual examination
3.3.1, 3.3.2
4.5.1
4.4.2.1
Workmanship
3.5
4.5.1
Tensile strength
3.4.7
4.6.5
1/ At the option of the manufacturer, documented in-process inspection may be used to
satisfy the requirements provided that all of the manufacturer's in-process control data
on these tests are made available to the Government upon request.
TABLE IX. Zero defect sampling plan.
Lot size
Minimum number of matched
impedance splices to be tested 1/
14
All
5 50
5
51 90
7
91 150
11
151 280
13
281 500
16
501 1200
19
1201 3200
23
3201 10000
29
10001 35000
35
1/ For lot sizes that are less than the required sample size, all matched impedance splices
shall be tested.
4.4.3 Group B inspection. Group B inspection shall consist of the tests specified in table
X. Group B inspection shall be made on matched impedance splices selected from inspection lots
that have passed Group A inspections.
15
