MIL-PRF-32517
TABLE II. Maximum dimensions.
Matched impedance splice
D (inches)
L (inches)
part number
Maximum
Maximum
M32517-RG142
.393 (10 mm)
2.56 (65 mm)
M32517-RG179
---
---
M32517-RG302
---
---
M32517-RG316
---
---
M32517-RG393
.630 (16mm)
2.56 (65 mm)
M32517-RG400
.433 (11 mm)
2.56 (65 mm)
FIGURE 1. Matched impedance splice dimensions.
5
