MIL-PRF-32517
(Copies of these documents are available online at https://www.ecianow.org.)
SAE INTERNATIONAL
SAE AMS1424
-
Fluid, Deicing/Anti-icing,
Aircraft SAE Type I
SAE AS22520
-
Crimping Tools, Wire Termination, General
Specification for
SAE AMS-DTL-23053
-
Insulation Sleeving, Electrical, Heat Shrinkable,
General Specification for
(Copies of these documents are available online at https://www.sae.org.)
2.4 Order of precedence. Unless otherwise noted herein or in the contract, in the event of
a conflict between the text of this document and the references cited herein, the text of this
document takes precedence. Nothing in this document, however, supersedes applicable laws and
regulations unless a specific exemption has been obtained.
3. REQUIREMENTS
3.1 Qualification. Matched impedance splices furnished under this specification shall be
products that are authorized by the qualifying activity for listing on the applicable qualified
products list before contract award (see 4.3 and 6.3).
3.2 Cable. Matched impedance splices shall be compatible with the cables conforming to
the electrical performance requirements of MIL-DTL-17.
3.3 Matched impedance splice assembly performance. The matched impedance splice
assembly shall conform to the requirements specified herein.
3.3.1 Sealing sleeve. If a sealing sleeve is part of the splice assembly, the sealing sleeve
component of the splice assembly shall conform to the longitudinal change, uninstalled recovery,
and copper corrosion requirements of SAE AMS-DTL-23053.
3.3.2 Metal crimp splice. When a metal crimp barrel is used to join the inner conductor
or shielding of the MIL-DTL-17 cable, SAE AS22520 crimp tools, dies and gages shall be
used to install the metal crimp barrel. If an existing SAE AS22520 crimp tool is not
available, the manufacturer shall request authorization from the procuring activity to
provide a non SAE AS22520 tool.
3.3.3 Design. The matched impedance splice shall meet the maximum dimensions of
Table II and Figure 1.
