MIL-PRF-32517
TABLE VII. Retention of qualification inspections.
Requirement
Test method
Examination or Test
paragraph
paragraph
Group I (10 specimens)
Visual examination
3.3.1, 3.3.2
4.5.1
Workmanship
3.5
4.5.1
Group III (3 matched impedance splice assemblies) 1/
3.4.1
4.6.1
Characteristic impedance
3.4.2
4.6.2
Insertion loss
3.4.3
4.6.3
Return loss
Dielectric withstanding voltage (dry)
3.4.6
4.6.8.1
Group IV (3 matched impedance splice assemblies)
Voltage drop (initial)
3.4.4
4.6.4
Thermal shock
3.4.8
4.6.6.3
Voltage drop (after test)
3.4.4
4.6.4
Group V (4 matched impedance splice assemblies) 1/
Environmental conditioning
3.4.4
4.6.4
Voltage drop (pre-test)
3.4.9
4.6.6.1
Altitude immersion (3 cycles)
3.4.5
4.6.7
Insulation resistance
---
4.6.6.5
Immersion
3.4.9
4.6.6.1
Altitude immersion (1 cycle)
3.4.5
4.6.7
Insulation resistance
3.4.8
4.6.6.3
Thermal shock
3.4.9
4.6.6.1
Altitude immersion (1 cycle)
3.4.5
4.6.7
Insulation resistance
3.4.11
4.6.6.4
Moisture resistance
3.4.9
4.6.6.1
Altitude immersion (1 cycle)
3.4.5
4.6.7
Insulation resistance
3.4.13
4.6.10
Heat aging
3.4.9
4.6.6.1
Altitude immersion (1 cycle)
3.4.5
4.6.7
Insulation resistance
3.4.2
4.6.2
Insertion loss
3.4.3
4.6.3
Return loss
3.4.6
4.6.8.2
Dielectric withstanding voltage (wet)
3.4.4
4.6.4
Voltage drop (after test)
3.4.7
4.6.5
Tensile strength
1/ The matched impedance splice assemblies shall be installed on MIL-DTL-17 cables with
cable leads at least 5 feet in length (10 feet total length). See 4.2.2.
4.4 Conformance inspection. Conformance inspection shall consist of Group A
examinations and test (see table VIII) and Group B inspections (see table X).
