MIL-PRF-32517
TABLE VI. Qualification inspections.
Examination or test
Requirement paragraph
Test method paragraph
Group I (19 specimens) 1/, 2/, 3/
Visual examination
3.3.1, 3.3.2
4.5.1
Workmanship
3.5
4.5.1
Group II (1 uninstalled sealing sleeve)
3.4.15
4.6.12
Copper mirror corrosion
Group III (3 matched impedance splice assemblies) 1/, 3/
3.4.1
4.6.1
Characteristic impedance
3.4.2
4.6.2
Insertion loss
3.4.3
4.6.3
Return loss
3.4.6
4.6.8.1
Dielectric withstanding voltage (dry)
Group IV (3 matched impedance splice assemblies)
Voltage drop (initial)
3.4.4
4.6.4
Thermal shock
3.4.8
4.6.6.3
Voltage drop (after test)
3.4.4
4.6.4
Group V (4 matched impedance splice assemblies) 1/, 2/
Environmental conditioning
3.4.9
4.6.6.1
Altitude immersion (3 cycles)
3.4.5
4.6.7
Insulation resistance
---
4.6.6.5
Immersion
3.4.9
4.6.6.1
Altitude immersion (1 cycle)
3.4.5
4.6.7
Insulation resistance
3.4.8
4.6.6.3
Thermal shock
3.4.9
4.6.6.1
Altitude immersion (1 cycle)
3.4.5
4.6.7
Insulation resistance
3.4.11
4.6.6.4
Moisture resistance
3.4.12
4.6.9
Vibration
3.4.9
4.6.6.1
Altitude immersion (1 cycle)
3.4.5
4.6.7
Insulation resistance
3.4.13
4.6.10
Heat aging
3.4.9
4.6.6.1
Altitude immersion (1 cycle)
3.4.5
4.6.7
Insulation resistance
3.4.2
4.6.2
Insertion loss
3.4.3
4.6.3
Return loss
3.4.6
4.6.8.2
Dielectric withstanding voltage (wet)
3.4.4
4.6.4
Voltage drop (after test)
3.4.7
4.6.5
Tensile strength
12
