MIL-PRF-32517
3.4 Performance characteristics.
3.4.1 Characteristic impedance. When matched impedance splice assemblies are tested
as specified in 4.6.1, the characteristic impedance shall not exceed the impedance limits shown
in Table III.
TABLE III. Characteristic impedance.
Matched impedance splice
Impedance
part number
(Ohms)
M32517-RG142
48 - 55
M32517-RG179
M32517-RG302
M32517-RG316
M32517-RG393
46 57.5
M32517-RG400
48 - 55
3.4.2 Insertion loss. When matched impedance splice assemblies are tested as
specified in 4.6.2, the insertion loss shall not exceed one decibel (dB) above the limits
throughout the frequency range up to 3 gigahertz (GHz) as specified in applicable cable
MIL-DTL-17 specification sheet (see 6.5). At the limit of the frequency range for MIL-DTL-17
cables operating above 3 GHz, the insertion loss limit shall increase linearly to 3dB above the
MIL-DTL-17 limits, at the highest rated frequency (see Table IV).
6
