MIL-DTL-83454A
1.3 Part or identification number (PIN). The PIN to be used for stud terminals acquired
M 83454/X - B A X XX
Example PIN: M83454/4-BA208
Stud thread length, in 16ths of an inch (see 1.2.1.3)
Grip, in 16ths of an inch (see 1.2.1.2)
Sleeve material [placeholder] (see 3.2.1)
Stud material (see 1.2.1.1)
A - 4140 chrome-molybdenum steel
B - 8740 chrome-nickel-molybdenum steel
C - 4340 chrome-nickel-molybdenum steel
Specification number and slash number
Denotes military specification
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3 and 4 of this
specification. This section does not include documents cited in other sections of this specification or
recommended for additional information or as examples. While every effort has been made to
ensure the completeness of this list, document users are cautioned that they must meet all specified
requirements of the documents cited in sections 3 and 4 of this specification, whether or not they are
listed.
2.2 Government documents.
2.2.1 Specification, standards, and handbook. The following specification, standards,
and handbook form a part of this document to the extent specified herein. Unless otherwise
specified, the issues of these documents are those cited in the solicitation or contract.
FEDERAL STANDARD
FED-STD-H28/4
- Screw-Thread Standards for Federal Services,
Section 4, Controlled Radius Root Screw Threads,
UNJ Symbol
DEPARTMENT OF DEFENSE SPECIFICATION
MIL-DTL-5541
- Chemical Conversion Coatings on Aluminum and
Aluminum Alloys
6
