MIL-DTL-83454A

TABLE VII. Conformance inspection.

Examination

Requirement paragraph

Method paragraph

Materials

Design and construction

Workmanship

Mounting examination

Voltage drop

Torque

4.4.1 Inspection of product for delivery. Inspection of product for delivery shall consist

of conformance inspection.

4.4.2 Inspection lot. An inspection lot shall consist of all terminals of the same part

number, produced under essentially the same conditions, and offered for inspection at one time.

4.4.2.1 Sampling plan. Statistical sampling and inspection shall be in accordance with

ASQ Z1.4, level II. The acceptance quality limit (AQL) shall be as specified in the procurement

contract (see 6.2).

4.4.2.2 Rejected lots. If an inspection lot is rejected, the supplier may rework it to

correct the defects, or screen out the defective units, and resubmit for reinspection. Such lots

shall be separate from new lots, and shall be clearly identified as reinspection lots.

4.4.3 Periodic inspection. Periodic inspection, if required by the procuring activity, shall

consist of those inspections listed under conformance inspections in table VII (see 6.2).

4.5 Methods of examination and test. The following methods of examination and testing

shall be used for determining suitability for use of the terminal studs. Sample parts that do not

meet the requirements stated herein shall result in the rejection of the first article (see 4.3.4) or

the lot (see 4.4.2.2).

4.5.1 Visual and mechanical examination. Stud terminals shall be examined to verify

that the design, construction, physical dimensions, and workmanship are in accordance with the

applicable requirements (see 3.2 to 3.3.2, inclusive, and 3.13). Terminal studs failing to exhibit

adherence to the design, construction, dimensional, and workmanship requirements specified

herein shall result in the rejection of the first article (see 4.3.4) or the lot (see 4.4.2.2).

4.5.2 Specified mounting. When required, stud terminals shall be mounted in a 2024,

temper T3, aluminum mounting panel per SAE AMS-QQ-A-250/4 of specified grip and drilled

to the specified installation hole diameter (see tables I through IV). The installation tool shall

meet the requirements of 3.4.
