MIL-DTL-83454A
4.5.9 Humidity. Stud terminals shall be tested in accordance with method 103 of
MIL-STD-202 (see 3.11). The following details and exceptions shall apply:
(a) Mounting - As specified in 4.5.2.
(b) Measurements after conditioning - Not applicable.
(c) Test condition A.
(d) Whether a direct current potential shall be applied during testing - Including test
voltage, duration of application of voltage, and points of application to the test sample (see 6.2).
(e) Examinations after exposure - Stud terminals shall be visually examined for evidence
of deterioration, corrosion, or other physical damage. Terminal studs exhibiting deterioration,
damage due to corrosion, or mechanical damage after the application of the humidity test, or that
fail to pass the follow-on voltage drop test specified in 4.5.3, shall result in the rejection of the
first article (see 4.3.4).
4.5.10 Bending force. Bending force shall be applied at right angles to the stud
terminals as close to the end as is practicable (see 3.12). The following conditions shall apply:
(a) Mounting - As specified in 4.5.2.
(b) Bending force - As specified (see table X).
(c) Examinations after test - Stud terminals shall be visually examined for evidence of
physical damage, including bending, breaking, cracking or sleeve/stud rotation. Terminal studs
exhibiting physical damage after the application of rated bending force shall result in the
rejection of the first article (see 4.3.4).
TABLE X. Bending force.
Bending force
Stud
(pounds)
size
(min)
0.138
140
0.164
200
0.190
300
0.250
500
5. PACKAGING
5.1 Packaging. For acquisition purposes, the packaging requirements shall be as
specified in the contract or order (see 6.2). When packaging of materiel is to be performed by
DoD or in-house contractor personnel, these personnel need to contact the responsible packaging
activity to ascertain packaging requirements. Packaging requirements are maintained by the
Inventory Control Point's packaging activities within the Military Service or Defense Agency, or
within the military service's system commands. Packaging data retrieval is available from the
managing Military Department's or Defense Agency's automated packaging files, CD-ROM
products, or by contacting the responsible packaging activity.
15
