MIL-DTL-24558/22B
5. Enclosure. The enclosures shall be a 15-foot submersible type.
6. Finish. The interior of the enclosures may be painted or left unpainted at the
contractor's option.
7. Weight. The weight of the connection boxes shall not exceed 23.0 pounds.
QUALITY ASSURANCE: First article inspection and quality conformance inspection shall be
as specified in MIL-DTL-24558.
NOTES:
1. Drawing. The terminal box specified by this specification sheet was formerly
covered on NAVSHIPS drawing no. 9000-S6202-74194.
2. Part or identifying number (PIN). The PIN to be used for terminal boxes acquired to
this specification is created as follows:
M 24558/22 - XXXX
Symbol number (see table II)
Specification sheet number
General specification number
Denotes military specification
TABLE I. Parts list.
Part number or
Item
Description
Qty
specification
Remarks
1
Enclosure assembly, brass with
1
MIL-E-24142/6
M24142/6-001
type A cover
2
Identification plate
1
MIL-DTL-24558
Figure 6
3
Information plate
1
MIL-DTL-24558
Figure 6
4
Terminal board base
1
Figure 4
MIL-I-24768/1
type GME
5
Mounting bracket
2
MIL-DTL-24558
Figure 2
6
Terminal lug assembly
2
Figure 5
Copper
7
HEXHD machine screw 5/16-18 X 1.250
4
Commercial
Brass
8
RDH machine screw 5/16-18 X 1.000
4
Commercial
Brass
9
Washer, 5/16 internal tooth
8
Commercial
Bronze
10
RDH machine screw 5/16-18 X 0.875
4
Commercial
Brass
11
RDH machine screw 6-32 X 0.188
4
Commercial
Brass
2
