MIL-DTL-24558-25 Terminal Boxes, Connection, Submersible \(15-Foot\), 500 Volts, Three-Phase, Symbol No. 418.1 - Six Bus Lugs For Two 3-Conductor 250 Mcm Cables, Symbol No. 418.2 - Six Bus Lugs For Two 3-Conductor 300 Mcm Cables, Symbol No. 418.3 - Six Bus Lugs For Two 3-Conductor 400 Mcm Cables

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10


MIL-DTL-24558/25B
TABLE FOR DRILLING TERMINAL CAP AND PAD
Symbol numbers
Cable size MCM
ØX drill
Y
418.1
250
5/8
.188
418.2
300
11/16
.188
418.3
400
13/16
.188
FIGURE 5. Terminal lug assembly.
