MIL-DTL-24558/25B
TABLE I. Parts list.
Part number or
Item
Description
Qty
specification
Remarks
1
Enclosure assembly, brass with
1
MIL-E-24142/6
M24142/6-008
type A cover
2
Identification plate
1
MIL-DTL-24558
Figure 6
3
Information plate
1
MIL-DTL-24558
Figure 6
4
Terminal board base
1
Figure 4
MIL-I-24768/1
type GME
5
Mounting bracket
4
MIL-DTL-24558
Figure 2
6
Terminal lug assembly, straight
1
Figure 5, A
7
Terminal lug assembly, angled
2
Figure 5, B
8
Hex head cap screw 5/16-18 X 1.125
24
Commercial
Brass
9
RDH machine screw 5/16-18 X 0.875
6
Commercial
Brass
10
Washer, 5/16 internal tooth
6
Commercial
Bronze
11
Washer, #10 internal tooth
9
Commercial
Bronze
12
RDH machine screw 1/4-20 X 0.625
9
Commercial
Brass
13
RDH machine screw 6-32 X 0.188
4
Commercial
Brass
TABLE II. Symbol numbers and general information.
For cable size MCM 1
Symbol number
418.1 2
250
418.2
300
418.3
400
1
MCM is defined as thousand circular mils.
2
Only this connection box will be stocked in the
supply system. For other symbol numbers, installing
activity should drill terminal lugs for "ØX" and "Y"
dimensions shown on figure 5.
3
