3.8 Identification plate. Unless otherwise specified (see 6.2), the
following information shall be permanently installed on the terminals, plugs,
and switch enclosures by molding on to the items or by installing
identification and information plates:
a. Military part number.
b. Symbol number.
c. Manufacturer's name, logo, Commercial and Government Entity (CAGE)
code.
d. Contract number, optional, or when required by Contracting Officer.
4.
VERIFICATION
4.1 Classification of inspections. The inspection requirements
specified herein are classified as follows:
a. Qualification inspection (see 4.2).
b. Conformance inspection (see 4.3).
4.2 Qualification inspection. Qualification inspection shall consist
of the examination and tests as specified in table I in the order shown.
Qualification inspection shall be conducted at a laboratory satisfactory to
the Government (see 6.3) on sample units produced with equipment and procedure
normally used in production (see 4.4).
4.2.1 Extension of qualification. Except for the cable entrance,
qualification approval of back-connected terminals may be extended to cover
the upper and lower riser terminals, provided they are of the same design and
construction and that qualification testing for high-impact shock and
vibration was accomplished without the use of a bulkhead seal.
TABLE I.
Qualification and inspection.
Sample
Sample
Test
Examination/test
1
2
Requirement
method
General examination
X
3.1, 3.3, 3.4, 3.5,
X
4.6.1
3.7, and
3.8
Dielectric
3.6.1
X
4.7.1
withstanding voltage
X
Insulation resistance
3.6.2
X
4.7.2
X
Contact engaging and
3.6.3
X
4.7.3
separating force
X
3.6.4
X
Plug engaging and
4.7.4
separating force
X
3.6.5
X
Cable pull-out 1/
4.7.5
Ambient temperature
X
3.6.6
X
4.7.6
extremes 2/
Contact resistance
X
3.6.7
4.7.7
Humidity 2/
3.6.8
X
4.7.8
Fluid immersion 1/
X
3.6.9
4.7.9
Electrical load 2/
X
3.6.10
4.7.10
Durability
X
3.6.11
4.7.11
X
High impact shock
3.6.12
4.7.12
X
Mechanical abuse 1/
3.6.13
4.7.13
Vibration
X
3.6.14
4.7.14
Salt spray
X
3.6.15
4.7.15
Watertightness 3/
X
3.6.16
4.7.16
Watertightness 4/
X
X
3.6.16
4.7.17
1/ Plugs only.
2/ Not applicable for switches.
3/ Bulkhead terminals only (see 6.1).
8
