MIL-DTL-15659J
TABLE I. Examinations.
Defect
Method of
classification
Requirement
inspection
Examination
paragraph
Major
Minor
Material
3.2
101
Certification
Dimensions:
---
---
---
Diameter of holes
102
Gage
Distance between hole centers
Gage
201
3.3.1
Length
202
Gage
Thickness
203
Gage
Width
204
Gage
Radius incorrect
205
Visual
Protective finish missing or inadequate
3.3.2
Visual
103
Workmanship
3.6
206
Visual
TABLE II. Tests.
Requirement
Test
Inspection
paragraph
paragraph
Solderability
3.4.1
4.4.1
Bending
3.4.2
4.4.2
Salt spray (corrosion)
3.4.3
4.4.3
Compression
3.4.4
4.4.4
Flattening resistance
3.4.5
4.4.4
4.3 Conformance inspection.
4.3.1 Inspection lot. An inspection lot shall consist of lug terminals of the same class
produced under the same production processes and offered for inspection at one time.
4.3.2 Conformance inspection. Conformance inspection shall be in accordance with
MIL-STD-1916 and shall consist of sampling plan A (see 4.3.2.1) or sampling plan B (see 4.3.2.2)
as specified (see 6.2).
4.3.2.1 Sampling plan A. Sampling plan A shall consist of the examinations listed in table I.
Unless otherwise specified (see 6.2), the manufacturer shall select the type of sampling plan
(attribute, variable, or continuous) in accordance with MIL-STD-1916. Sampling and inspection
shall be in accordance with verification level I of MIL-STD-1916.
4.3.2.2 Sampling plan B. Sampling plan B shall consist of sampling plan A plus the tests
listed in table II. Unless otherwise specified (see 6.2), the manufacturer shall select the type of
sampling plan (attribute, variable, or continuous) in accordance with MIL-STD-1916. Sampling
and inspection shall be in accordance with verification level I of MIL-STD-1916.
5
