MIL-DTL-24558/26B
TABLE I. Parts list.
Part number or
Item
Description
Qty
specification
Remarks
1
Enclosure assembly, brass with
1 MIL-E-24142/6
M24142/6-004
type A cover
2
Identification plate
1
MIL-DTL-24558
Figure 6
3
Information plate
1
MIL-DTL-24558
Figure 6
4
Terminal board base
1
Figure 4
MIL-I-24768/1
type GME
5
Mounting bracket
2
MIL-DTL-24558
Figure 2
6
Terminal bus cover
1
Figure 5
MIL-I-24768/1
type GME
7
Terminal bus assembly - phase "A"
2
Figure 6
Brass
and "C"
8
Terminal bus assembly - phase "B"
1
Figure 7
Brass
9
Terminal bus body
6
9000-S6202-73055,
Brass
pc 2
10
Terminal bus pressure screw assembly
6
9000-S6202-73055,
Brass
pc 22
11
Branch terminal body
6
9000-S6202-73246,
Brass
pc 3
12
Branch terminal pressure screw assembly
6
9000-S6202-73246,
Brass
pc 23
13
Terminal board spacer
2
Figure 8
MIL-I-24768/1
type GME
14
Barrier, 1-hole
4
Figure 9
MIL-I-24768/1
type GME
15
Insert
4
Figure 10
Steel
16
Barrier, 2-hole
2
Figure 11
MIL-I-24768/1
type GME
17
Spacer
6
Figure 12
Brass
18
RDH machine screw .138-32 X 0.188
4
Commercial
Brass
19
FLH machine screw .138-32 X 0.500
8
Commercial
Steel
20
RDH machine screw .190-24 X 0.562
9
Commercial
Brass
21
Washer, #10 internal tooth
9
Commercial
Steel
22
FLH machine screw .190-24 X 1.250
4
Commercial
Steel
23
RDH machine screw1/4-20 X 0.750
4
Commercial
Steel
24
Washer, 1/4 internal tooth
4
Commercial
Steel
3
