MIL-DTL-24558/24B
TABLE I. Parts list.
Part number or
Item
Description
Qty
specification
Remarks
1
Enclosure assembly, brass
1
MIL-E-24142/3
M24142/3-001
2
Identification plate
1
MIL-DTL-24558
Figure 6
3
Information plate
1
MIL-DTL-24558
Figure 6
4
Mounting pads
4
Figure 2
5
Terminal board base
1
Figure 4
MIL-I-24768/1
type GME
6
Terminal board sub-base
1
Figure 5
MIL-I-24768/1
type GME
7
Terminal body
6
9000-S6202-73246,
Brass
pc 3
8
Terminal pressure screw assembly
6
9000-S6202-73246,
Brass
pc 23
9
Terminal lug assembly, straight
1
Figure 6
10
Terminal lug assembly, 30-degree
2
Figure 6
11
RDH machine screw 1/4-20 X 0.625
4
Commercial
Brass
12
Washer, 1/4 internal tooth
4
Commercial
Bronze
13
RDH machine screw 6-32 X 0.188
4
Commercial
Brass
14
RDH machine screw 10-24 X 0.500
6
Commercial
Brass
15
Washer, #10 internal tooth
6
Commercial
Bronze
3
