MIL-DTL-24558/23B
TABLE I. Parts list.
Part number or
Item
Description
Qty
specification
Remarks
1
Enclosure assembly, brass
1
MIL-E-24142/4
M24142/4-001
2
Identification plate
1
MIL-DTL-24558
Figure 6
3
Information plate
1
MIL-DTL-24558
Figure 6
4
Terminal board base
1
Figure 4
MIL-I-24768/1
type GME
5
Mounting bracket
2
MIL-DTL-24558
Figure 2
6
Terminal body
6
9000-S6202-73055,
Brass
pc 3
7
Terminal pressure screw assembly
6
9000-S6202-73055,
Brass
pc 23
8
Terminal lug assembly, 15-degree
2
Figure 5
9
Terminal lug assembly, straight
1
Figure 6
10
RDH machine screw 1/4-20 X 0.750
4
Commercial
Brass
11
Washer, 1/4 internal tooth
4
Commercial
Bronze
12
RDH machine screw 6-32 X 0.500
4
Commercial
Brass
13
RDH machine screw 10-24 X 0.500
6
Commercial
Brass
14
Washer, #10 internal tooth
6
Commercial
Bronze
3
