MIL-DTL-24558/18B

4. Standard parts. The standard parts shown in table I shall be used in the construction

of the connection boxes specified herein. The numbers in circles shown on figures 1 and 2 are

the same as those shown in the "Item" column of table I.

5. Enclosure. The enclosures shall be a 15-foot submersible type.

6. Finish. The interior of the enclosures may be painted or left unpainted at the

contractor's option.

7. Weight. The weight of the connection boxes shall not exceed the following:

Symbol number 400.1 - 2.0 pounds

Symbol number 400.3 - 3.0 pounds

Symbol number 400.2 - 3.0 pounds

Symbol number 400.4 - 2.0 pounds

QUALITY ASSURANCE: First article inspection and quality conformance inspection shall be

as specified in MIL-DTL-24558.

NOTES:

1. Drawing. The terminal boxes specified by this specification sheet were formerly

covered on NAVSHIPS drawing no. 9000-S6202-74027.

2. Part or identifying number (PIN). The PIN to be used for terminal boxes acquired to

this specification is created as follows:

M 24558/18 - XXXX

Symbol number (see table II)

Specification sheet number

General specification number

Denotes military specification
