MIL-DTL-24558/1B
7. Maximum number of wires. The maximum number of wires (including spares) shall
not exceed three times the number of terminals. The maximum number of wires to be connected
to a single terminal shall not exceed three.
QUALITY ASSURANCE: First article inspection and quality conformance inspection shall be
as specified in MIL-DTL-24558.
NOTES:
1. Drawing. The terminal box specified by this specification sheet was formerly
covered on NAVSHIPS drawing no. 9000-S6501-74017.
2. Part or identifying number (PIN). The PIN to be used for terminal boxes acquired to
this specification is created as follows:
M 24558/1 - 520.1
Symbol number
Specification sheet number
General specification number
Denotes military specification
TABLE I. Parts list.
Part number or
Item
Description
Qty
specification
Remarks
Enclosure assembly, brass 1
1
1
MIL-E-24142/5
M24142/5-001
2
Identification plate
1
MIL-DTL-24558
Figure 6
3
Information plate
1
MIL-DTL-24558
Figure 6
4
Mounting pad
2
MIL-DTL-24558
Figure 5
5
Terminal board assembly
1
A-A-59125/12
6TB6
6
RDH machine screw 10-24 X 0.625
2
Commercial
Brass
7
Washer, #10 external tooth
2
Commercial
Bronze
1
Box piece 23, cover piece 2, and gasket piece 25 of NAVSEA drawing no. 9000-803-74210 may be used as an
alternate provided that the box height and mounting details are modified to comply to those specified herein.
2
